Name: Split Window, French Window, Double Inward Opening System Window, Bridge Cutoff Aluminum Window
Brand: EDUCE Home Furnishing
SKU: Seine EDUCE Grey System Window
Price: 1 USD
Availability: InStock
Rating: 4.9 (185 reviews)

Home > products > Aluminum Window >

Split Window, French Window, Double Inward Opening System Window, Bridge Cutoff Aluminum Window

Place of Origin:

Guangdong, China

Brand Name:

EDUCE Home Furnishing

Model Number:

Seine EDUCE Grey System Window

Request A Quote

Split Window, French Window, Double Inward Opening System Window, Bridge Cutoff Aluminum Window

Product Details

Wall Thickness Of Profile Frame:

1.8mm

Wall Thickness Of Profile Fan:

1.8mm

Border To Wall Thickness:

110mm

Opening Method:

Outer Horizontal Opening/outer Upper Suspension/outer Open Upper Suspension/split Window

Customization:

Yes

Glass Configuration:

5mm+19A (warm Edge Strip)+5mm

Glass Selection:

6mm+16A+6mm、8mm+24A+8mm、10mm+20A+10mm

Gauze Mesh:

Medium Transparency Yarn Mesh

Hinge:

Imported Weibizhi Internal Opening And Reversing Accessories (opening Angle 180 Degrees)

Handle:

Imported Weibizhi Baseless Handle (standard Black)

Locking System:

Silent Anti-theft And Anti Pry Locking Point Lock Seat.

Sealant Strip:

EPDM Composite Foam Sealant Strip.

Insulation Strip:

Baiyun Yile PA66 Nylon Insulation Strip

Thermal Insulation Performance W (㎡· K):

Level 5

Sound Insulation Performance (dB):

Level 4

Water Tightness Performance (Pa):

Level 6

Airtightness Performance:

Level 8

Wind Pressure Resistance Performance (KPa):

Level 9

Color Configuration:

EDUCE Grey

Payment & Shipping Terms

Minimum Order Quantity

10 Square Meters

Packaging Details

Foam packing with strong wooden pallets

Delivery Time

45 days

Payment Terms

T/T

RELATED PRODUCTS

86-757-8565-1691

Educe@door-window-educe.com

86-0757-8565-1691

Contact Now

Product Description

The main profile wall thickness is 1.8mm, and the frame and fan are designed flush, with a flat and smooth surface.Square pressing line design, stronger three-dimensional sense.The internal opening and broken bridge structure can balance ventilation and protection functions.Standard configuration 304# stainless alloy gauze, it can prevent mosquitoes and particles from entering indoor, with a higher protection coefficient.The double lock points design of the gauze fan, effectively solves the problem of gauze fan shaking.Glue injection expansion corner code process effectively increases splicing strength, stabilizes structure, and has better load-bearing capacity. Integrated circular arc angle protection, with a flat and seamless appearance, anti-knock and scratch.Standard configuration PA66 Nylon heat insulation strip, effectively achieving heat preservation and insulation performance.EPDM composite foam sealing rubber strip for better soundproof and waterproofing.Three seals at the opening position,effectively ensure air and water tightness; The obvious of drainage structure ensures smooth drainage and good sealing.
