Name: Colombia System Window
Brand: EDUCE Home Furnishing
SKU: Colombia System Window
Price: 1 USD
Availability: InStock
Rating: 4.7 (101 reviews)

Home > products > Aluminum Window >

Colombia System Window

Place of Origin:

Guangdong, China

Brand Name:

EDUCE Home Furnishing

Certification:

IDA Design Awards, GB/T 19001-2016/ISO 9001:2015, Muse Design Awards

Model Number:

Colombia System Window

Request A Quote

Product Details

Wall Thickness Of Profile Frame:

1.8mm

Wall Thickness Of Profile Fan:

1.9mm

Border To Wall Thickness:

110mm

Opening Method:

Inner Flat Opening/inner Inverted Opening

Customization:

Yes

Glass Configuration:

5mm+19A (warm Edge Strip)+5mm

Glass Selection:

6+16A+6、8+16A+8、10+22A+10、10+2.28pvb+10、12+3.04pvb+12

Gauze Mesh:

0.8 Thick 304 Alloy Steel Mesh Material

Hinge:

Imported Wihaagen Inner Open Inverted Quick Assembly Hardware Accessories (glass Fan)

Handle:

Vihagen No Base Handle

Locking System:

Imported Vihagen Transmission Box And Anti Prying Lock Point Lock Seat

Sealant Strip:

EPDM Composite Foam Sealant Strip.

Insulation Strip:

Baiyun Yile PA66 Nylon Insulation Strip

Thermal Insulation Performance W (㎡· K):

Level 6

Sound Insulation Performance (dB):

Level 4

Water Tightness Performance (Pa):

Level 6

Airtightness Performance:

Level 8

Wind Pressure Resistance Performance (KPa):

Level 9

Color Configuration:

Dior Phantom

Payment & Shipping Terms

Minimum Order Quantity

10square meters

Packaging Details

Foam packing with strong wooden pallets

Delivery Time

45 days

Payment Terms

T/T

RELATED PRODUCTS

86-757-8565-1691

Educe@door-window-educe.com

86-0757-8565-1691

Contact Now

Product Description

Columbia series is a broken bridge window and gauze fan integrated outward opening system window. The window and gauze fan integrated simple style design and the frame and the inner fan flush, full of aesthetic feeling, three-dimensional sense is stronger. At the same time, the gauze net is connected with the profile, which greatly enhances the impact resistance; which is ensuring the anti-mosquito effect and not affecting the indoor lighting. Heat insulation strip is designed on the same vertical line to achieve excellent waterproof sealing, soundproof and heat insulation performance.

Tags：

Send your inquiry directly to us
