Name: EDU75Hi Internal Opening System Window
Brand: EDUCE Home Furnishing
SKU: EDU75Hi Internal Opening System Window
Price: 1 USD
Availability: InStock
Rating: 4.8 (135 reviews)

Home > products > Aluminum Window >

EDU75Hi Internal Opening System Window

Place of Origin:

Guangdong, China

Brand Name:

EDUCE Home Furnishing

Certification:

IDA Design Awards, GB/T 19001-2016/ISO 9001:2015, Muse Design Awards

Model Number:

EDU75Hi Internal Opening System Window

Request A Quote

Product Details

Wall Thickness Of Profile Frame:

1.8mm

Wall Thickness Of Profile Fan:

1.8mm

Border To Wall Thickness:

75mm

Opening Method:

Opening Indoors

Customization:

Yes

Glass Configuration:

5mm+19A+5mm (warm Edge Strip)

Glass Selection:

5mm+12A+5mm+12A+5mm (warm Edge Strip), 6mm+27A+6mm (warm Edge Strip), 8mm+24A+8mm (warm Edge Strip), 10+2.28pvb+10

Gauze Mesh:

Optional Glass Guardrail Can Be Equipped With Rewinding Mesh (the Height Limit Of The Mesh Can Be Done Below 1700mm, But Cannot Be Exceeded)

Hinge:

Standard Imported Brand Internal Opening And Reversing Accessories (Savio)

Handle:

Standard Imported Brand Handle (Savio)

Locking System:

Standard Imported Brand Internal Opening And Reversing+multi Locking Point Locking System (Savio)

Sealant Strip:

EPDM Composite Foam Sealant Strip

Insulation Strip:

PA66 Nylon Insulation Strip (Baiyun Yile)

Thermal Insulation Performance W (㎡· K):

Level 6

Sound Insulation Performance (dB):

Level 4

Water Tightness Performance (Pa):

Level 6

Airtightness Performance:

Level 8

Wind Pressure Resistance Performance (KPa):

Level 9

Color Configuration:

Starry Sky Black

Payment & Shipping Terms

Minimum Order Quantity

10square meters

Packaging Details

Foam packing with strong wooden pallets

Delivery Time

45 days

Payment Terms

T/T

RELATED PRODUCTS

86-757-8565-1691

Educe@door-window-educe.com

86-0757-8565-1691

Contact Now

Product Description

From the fine selection of profiles to the product ingenuity, every detail we are carefully polished. Preferred profile, choose ultra-high precision grade 6060-T6 aluminum profile. The wall thickness is 1.8mm, meeting the new national standard. The frame and the fan adopt die casting expansion glue corner code connection process, with flat surface and stable structure. Three sealing design of the system,

EPDM continuous bending isobaric rubber strip, soft and hard supply composite technology, more soundproof and moer heat insulation, 30mm wide PA66 multi-cavity heat insulation strip, wear-resistant and anti-aging, with vertical isotherm design, comprehensively improve the heat insulation and preservation performance. The new zinc alloy material floor drain drainage system can easily deal with the large number of drainage needs caused by the wind and rain, and solve the problem of water overflow due to too small discharge. A full set of standard imported hardware system, equipped with no base handle, high appearance level, high performance, hidden hinge, high bearing capacity, easy to open and close. R3 rounded corner process design of the opening fan, anti-bump and anti-scratch, intimate design, safe and beautiful.
