Name: Harman casement window
Brand: EDUCE Home Furnishing
SKU: Harman casement window
Price: 1 USD
Availability: InStock
Rating: 4.5 (162 reviews)

Home > products > Aluminum Window >

Harman casement window

Place of Origin:

Guangdong, China

Brand Name:

EDUCE Home Furnishing

Certification:

IDA Design Awards, GB/T 19001-2016/ISO 9001:2015, Muse Design Awards

Model Number:

Harman casement window

Request A Quote

Product Details

Wall Thickness Of Profile Frame:

1.8mm

Wall Thickness Of Profile Fan:

1.8mm

Border To Wall Thickness:

116mm

Opening Method:

Swing

Customization:

Yes

Glass Configuration:

5mm+19A (warm Edge Strip)+5mm

Optional Large Glass:

8mm+19A (warm Edge Strip)+8mm, 10mm+20A (warm Edge Strip)+10mm

Gauze Mesh:

Standard Configuration Of 0.7mm Thick 304 Alloy Steel Mesh Material

Hinge:

Standard Configuration: EDU-B01 Load-bearing Hinge (invisible Hinge With Mesh Opening Angle Of 180)

Handle:

Standard Configuration Of German Imported Haobo Handle

Locking System:

Standard Silent Anti-theft And Anti Pry Locking Point Lock Seat, Safety Limiter.

Sealant Strip:

EPDM Composite Foam Sealant Strip

Insulation Strip:

PA66 Nylon Insulation Strip

Thermal Insulation Performance W (㎡· K):

Level 5

Sound Insulation Performance (dB):

Level 4

Water Tightness Performance (Pa):

Level 6

Airtightness Performance:

Level 8

Wind Pressure Resistance Performance (KPa):

Level 9

Color Profile:

Bordeaux Red

Payment & Shipping Terms

Minimum Order Quantity

10square meters

Packaging Details

Foam packing with strong wooden pallets

Delivery Time

45 days

Payment Terms

T/T

RELATED PRODUCTS

86-757-8565-1691

Educe@door-window-educe.com

86-0757-8565-1691

Contact Now

Product Description

Haman window and gauze fan integrated outward opening window, the wall thickness of the frame and fan is 1.8mm, in line with the new national standard; using the frame and fan inside and outside flush design & inclined line pressing, the surface is three-dimensional and beautiful; three adhesive strips are used to seal the opening position, better soundproof and heat insulation performance; isotherm vertical design, efficient barrier cold and heat conduction; standard R3 arc small corner protector, eliminate scratching hazard; The gauze mesh is using the bending process to connect the window frame,which is making the structure more stable, the glass adopts an internal and external pressing adhesive strip process, greatly improving the stability and wind pressure resistance of the glass; optional safety grid device, improve safety and anti-theft performance; implicit drainage structure design, with windproof and drainage cover, drainage more smoothly.
